MSI MEGA ePower 200AV+ User Manual

2
Figure 1-1 PLC Application
1.3 System Requirements
Operating System Microsoft Windows 2000 or XP , Vista 32-bit
CPU Intel Pentium III or better, clock rate faster than 2.0GHz
recommended
RAM At least 128MB
Screen Resolution Any resolution
Free Disk Space At least 20MB
Network Interface At least one Fast Ethernet (100 Mbps) network card, and
Ethernet Cord
1.4 Package Contents
 MEGA ePower 200AV+ device
(1 device for single pack, 2 devices for duo pack)
 CD ROM x 1
 RJ45 Ethernet cable
(1 cable for single pack, 2 cables for duo pack)

MSI MEGA ePower 200AV+ Specifications

General

Chipset	Intellon INT6400/INT1400
LED’s	Power Ethernet: Ethernet Link and Activity Data: PLC Link and Activity
Push Button	Reset: Restore the default factory parameter Security: Set up network password automatically
Protocol	HomePlug AV 1.0 Co-exists with existing HomePlug 1.0
PLC Rate	200Mb
Modulation Band	2-30MHz
Modulation Schemes	Supports1024/256/64/16/8-QAM, QPSK, BPSK and ROBO
Encryption	128 AES
System Support	Windows 98SE, 2000, ME, XP 32/64 bit and Vista 32/64bit
Outlet current	220VAC 16A Maximum，110VAC 20A Maximum
Consumption	3.5W
Input Rating	100-240 VAC, 50/60Hz
Filter characteristics	-22 dB to -45 dB
Certifications	CE, UL, FCC Part 15 Class B
Green Standard	RoHS
Operating Temperature	0º to 45º C
Storage Temperature	-20 º to 70 º C
Operating Humidity	10% to 90% Non-condensing
Storage Humidity	5% to 90% Non-Condensing

Weight and Dimensions

Physical Characteristics	L×W×H: 130.5mm×69mm×79mm
Weight	233g
