Onboard LEDs

Debug Code LED Table

SEC Progress Codes

01 Power on. Reset type detection (soft/hard)

02 AP initialization before microcode loading

03 System Agent initialization before microcode loading

04 PCH initialization before microcode loading

06 Microcode loading

07 AP initialization after microcode loading

08 System Agent initialization after microcode loading

09 PCH initialization after microcode loading

0B Cache initialization

SEC Error Codes

0C - 0D Reserved for future AMI SEC error codes

0E Microcode not found

0F Microcode not loaded

PEI Progress Codes

10 PEI Core is started

11 

12 - 14 

15 

16 - 18 

19 

1A - 1C 

2B Memory initialization. Serial Presence Detect (SPD) data reading

2C Memory initialization. Memory presence detection

2D Memory initialization. Programming memory timing information

2E Memory initialization. Configuring memory

2F Memory initialization (other)

31 Memory Installed

32 

33 

34 

35 



initialization

37 

38 - 3A 

Other manuals for MSI MPG Z690 CARBON WIFI

Questions and Answers:

Need help?

Do you have a question about the MSI MPG Z690 CARBON WIFI and is the answer not in the manual?

General

Form Factor	atx
Chipset	z690
Chipset Compatibility	intel
Processor Socket	socket lga 1700
Processor Compatibility	intel, intel core i9, intel core i7, intel core i5, intel core i3
RAID	raid 0, raid 1, raid 5
Multi-GPU	crossfire
Memory Type	ddr5
Memory Speeds	6666
SATA Connectors	6x sata 6g
Wireless Standard	ax
Wireless Networking Standard	wi-fi 6e
Wireless Connectivity	bluetooth, wi-fi
USB Ports	6 x usb-a 3.2, 1 x usb-c 3.2, 4 x usb-a 2.0
Audio Ports	1x front audio (jaud)
Audio Channels	8
M.2 Slots	5
