MSI PRO H610M-G User Manual

17
󻢚󻊺󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻂆󻢚󻊺󼏂󼏢󺪢󻈛󻂺󻃖󼖂󻼪󽍎󺺦󼒛󺫮󻺞󼒛󻨛󻪇󼔲
󻫦󼌺󽋾󻖝󽇮󻼖󻡷󻼎󻝮󼨪󼙢󽍊󻼪󼒆
󽌲 󼃒󽐪󼕦󻝶 󽌲 󼃒󽐪󼕦󻝶
1 SPI Power 2 SPI Chip Select
3
Master In Slave Out
(SPI Data)
4
Master Out Slave In
(SPI Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request
1
2 12
11

󼜃󼒆󻺞󽍟
 󼳖󺼗󼼢󻂆󼭎󻃲󼘇󺪛󼗶󻘗󼏂󻼎󼭎󻃲󻧪󼼢󼏢󻽿󼂖󽂪󻞯
󼔶󼞲󼓂󽍛󻂺󻃖
 󼂖󽂪󻞯󼔶󻼖󼱊󻐂󻂆󼘎󺩢󽍊󺰢󼗶󼏂󽍟󻺳󼗶󼓂󺫧󺯻󼖗󼱊󼕊󼗶󼓂󼔶󺸶󺫒󼗶󼓂
󼵆󻋎󻝮󼵊󻼮󽂪󼏂󻼎󻵃󼌶󼛮󻼪󼒆
 󻽾󽋶󽂪󼓚󼎦󻝮󻺞󼒛󽍊󼏞󽑇󼖗󻈎󼂖󽂪󻞯󼔶󼙢󼘇󽍊󻼪󼒆
󼳖󺼗󼼢󼒛
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼂖󽂪󻞯󼔶󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖
󽌲 󼃒󽐪󼕦󻝶 󽌲 󼃒󽐪󼕦󻝶
1 +12V 2 G
3 R 4 B
1

MSI PRO H610M-G Specifications

General

Form Factor	Micro-ATX
Chipset	Intel H610
Socket	LGA 1700
Memory Slots	2 x DIMM
Maximum Memory	64GB
PCIe Slots	1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
SATA Ports	4 x SATA 6Gb/s
Video Outputs	1 x HDMI, 1 x VGA
Memory Speed	DDR4 3200 MHz
M.2 Slots	1 x M.2
Audio	Realtek ALC897
LAN	Realtek RTL8111H Gigabit LAN
USB Ports	4 x USB 3.2 Gen 1, 6 x USB 2.0
