MSI PRO H610M-G User Manual

3
Specifications
CPU
 Supports 12th Gen Intel® Core™ Processors, Pentium®
Gold and Celeron® Processors
 Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset
Intel® B660 Chipset (PRO B660M-E DDR4/ B660M BOMBER
DDR4)
Intel® H610 Chipset (PRO H610M-G DDR4/ PRO H610M-B
DDR4/ H610M BOMBER DDR4)
Memory
 2x DDR4 memory slots, support up to 64GB*
 Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
 Max overclocking frequency: (For B660 chipset only)
• 1DPC 1R Max speed up to 4600+ MHz
• 1DPC 2R Max speed up to 4000+ MHz
 Supports Dual-Channel mode
 Supports non-ECC, un-buffered memory
 Supports Intel® Extreme Memory Profile (XMP) (For B660
chipset only)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
 1x PCIe x16 slot (From CPU)
• Supports up to PCIe 4.0 x16
 1x PCIe x1 slot (From B660/ H610 chipset)
• Supports PCIe 3.0 x1
 1x M.2 slot with E-key for PCIe WiFi module only (M2_
WIFI1)(For PRO H610M-G DDR4 & PRO H610M-B DDR4)
Onboard Graphics
 1x HDMI 2.1 with HDR port, supports a maximum
resolution of 4K 60Hz*
/
**
 1x VGA port, supports a maximum resolution of
2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*
/
**
 1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz*
/
**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
 4x SATA 6Gb/s ports (From B660/ H610 chipset)*
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
Continued on next page

MSI PRO H610M-G Specifications

General

Form Factor	Micro-ATX
Chipset	Intel H610
Socket	LGA 1700
Memory Slots	2 x DIMM
Maximum Memory	64GB
PCIe Slots	1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
SATA Ports	4 x SATA 6Gb/s
Video Outputs	1 x HDMI, 1 x VGA
Memory Speed	DDR4 3200 MHz
M.2 Slots	1 x M.2
Audio	Realtek ALC897
LAN	Realtek RTL8111H Gigabit LAN
USB Ports	4 x USB 3.2 Gen 1, 6 x USB 2.0
