MSI Z170A MPOWER GAMING TITANIUM User Manual

16
Specifications
Specifications
CPU
Supports 6th Gen Intel
®
Core
™
i3/i5/i7 processors, and Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
Z170 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
 Supports DDR4 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/
2600(OC)/ 2400/ 2133 MHz
y Dual channel memory architecture
y Supports ECC, un-buffered memory
 ECC UDIMM memory (non-ECC mode)*
y Supports Intel
®
Extreme Memory Profile (XMP)
* For the latest information about memory, please visit http://www.msi.com
Expansion Slots
y 3x PCIe 3.0 x16 slots*
y 3x PCIe 3.0 x1 slots*
* PCI_E6 slot and PCIe x1 slots share the same bandwidth. Please refer to
page 30 for PCIe slots bandwidth table.
Multi-GPU
y Supports 3-Way AMD
®
CrossFire
™
Technology
y Supports 2-Way NVIDIA
®
SLI
™
Technology
USB
y ASMedia
®
ASM1142 Chipset
 1x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) port on the
back panel
 1x USB 3.1 Gen2 (Super Speed USB 10Gbps) Type-C port
on the back panel
y Intel
®
Z170 Chipset
 6x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the
back panel, 4 ports available through the internal USB
connectors)
 1x USB 3.1 Gen1 (SuperSpeed USB) Type-C port on the
board
 6x USB 2.0 (High-speed USB) ports (4 ports on the
back panel, 2 ports available through the internal USB
connector)
Continued on next page

MSI Z170A MPOWER GAMING TITANIUM Specifications

General

Chipset	Intel Z170
CPU Socket	LGA 1151
Max Memory	64 GB
Form Factor	ATX
USB 3.1 Gen1 (Rear)	4
USB 2.0 (Rear)	2
Audio	Realtek ALC1150
LAN	Intel I219-V Gigabit LAN
PCIe x16 Slots	3
PCIe x1 Slots	3
Memory Slots	4
Multi-GPU Support	AMD 3-Way CrossFireX, NVIDIA 2-Way SLI
SATA Ports	6
M.2 Slots	2
RAID Support	0, 1, 5, 10
Memory Speed	2133/2400/2600/2800/3000/3200 MHz (OC)
USB 3.1 Ports	1 (Type-C), 1 (Type-A)
