MTS Sensors Temposonics E-Series Brief Instructions

Temposonics
®
E-Series
Brief Instructions
I 4 I
2.1 Intended use
This product may be used only for the applications defined
under item 1 and only in conjunction with the third-party
devices and components recommended or approved by MTS
Sensors. As a prerequisite of proper and safe operation the
product requires correct transport, storage, mounting and
commissioning and must be operat ed with utmost care.
1. The sensor systems of all Temposonics
®
series are
intended exclusively for measurement tasks encountered
in industrial, commercial and laboratory applications. The
sensors are considered as system accessories and must
be connected to suitable evaluation electronics, e.g. a
PLC, IPC, indicator or other electronic control unit.
2.2 Forseeable misuse
Forseeable misuse Consequence
Wrong sensor connection The sensor will not work
properly or will be destroyed
Operate the sensor out off
the operating temperature
No signal output
The sensor can be damaged
Power supply is out of the
defined range
Signal output is wrong /
no signal output /
the sensor will be damaged
Position measurement is
influenced by an external
magnetic field
Signal output is wrong
Cables are damaged Short circuit – the sensor can
be destroyed / sensor does
not respond
Spacers are missing /
are installed in a wrong order
Error in position
measurement
Wrong connection
of ground / shield
Signal output is disturbed
The electronics can be
damaged
Use of a magnet that is not
certified by MTS Sensors
Error in position
measurement
Do not reprocess the sensor afterwards.
 The sensor might be damaged.
Do not step on the sensor.
 The sensor might be damaged.
2. Safety instructions
Manuals, Software & 3D Models
available at: www.mtssensors.com
