MTS Sensors Temposonics E-Series Brief Instructions

Temposonics
®
E-Series
Brief Instructions
I 7 I
Sensor electronics housing
Position magnet
(Block magnet)
Connector outlet
Sensor profile with sensor element
Ground lug
Mounting clamp
3.4 Temposonics
®
E-Series EP2
3.3 Temposonics
®
E-Series EL
Available outputs:
• Analog
• Start / Stop
• SSI
• CANopen
• IO-Link
Available outputs:
• Analog
• Start / Stop
• SSI
• CANopen
• IO-Link
Available outputs:
• Analog
• Start / Stop
• SSI
• CANopen
• IO-Link
(ultra low profile sensor)
(smooth profile sensor)
Connector outlet
Mounting clamp
Adjustable rod end
Sensor profile with sensor element
Sensor electronics housing
Mounting clamp
Position magnet
(Magnet slider or block magnet)
Connector outlet
Sensor profile with sensor element
Ground lug
3.5 Temposonics
®
E-Series ER
(rod & cylinder housing)
Manuals, Software & 3D Models
available at: www.mtssensors.com
