Temposonics
®
R-Series V SSI
Operation Manual
I 31 I
Output
Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422)
Data format Binary or gray
Data length 8…32 bit
Data transmission rate
70 kBaud
5
…1 MBaud, depending on cable length:
Cable length < 3 m < 50 m < 100 m < 200 m < 400 m
Baud rate 1 MBd < 400 kBd < 300 kBd < 200 kBd < 100 kBd
Measured value Position
Measurement parameters
Resolution: Position 0.1…100 µm (0.0001…0.1 mm)
Resolution: Velocity 0.001 mm/s (determined over 10 measured values)
Update rate
6
Stroke length 25 mm 300 mm 750 mm 1000 mm 2000 mm 6350 mm
Update rate 10 kHz 3.4 kHz 2.7 kHz 2.1 kHz 1.2 kHz 0.4 kHz
Linearity deviation
7
Stroke length ≤ 400 mm > 400 mm
Linearity deviation ≤ ±40 μm < ±0.01 % F.S.
Optional internal linearization: Linearity tolerance (applies for the rst magnet for differential measurement)
Stroke length 25...300 mm 300...600 mm 600...1200 mm 1200...3000 mm 3000...5000 mm 5000...6350 mm
typical ± 15 µm ± 20 µm ± 25 µm ± 45 µm ± 85 µm ± 95 µm
maximum ± 25 µm ± 30 µm ± 50 µm ± 90 µm ± 150 µm ± 190 µm
Repeatability < ±0.001 % F.S. (minimum ±2.5 μm) typical
Hysteresis < 4 µm typical
Temperature coefficient < 15 ppm/K typical
Operating conditions
Operating temperature −40…+85 °C (−40…+185 °F)
Humidity 90 % relative humidity, no condensation
Ingress protection IP67 (connectors correctly tted)/IP68 for cable output
Shock test 150 g/11 ms, IEC standard 60068-2-27
Vibration test 30 g/10…2000 Hz, IEC standard 60068-2-6 (excluding resonant frequencies)
EMC test Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
.
Magnet movement velocity Magnet slider: Max. 10 m/s; U-magnet: Any; block magnet: Any
Design/Material
Sensor electronics housing Aluminum (painted), zinc die cast
Sensor profile Aluminum
Stroke length 25…6350 mm (1…250 in.)
Mechanical mounting
Mounting position Any
Mounting instruction Please consult the technical drawings on page 11
8. Technical data
5/ With standard one shot of 16 μs
6/ Sensor with standard settings
7/ With position magnet # 252 182
8.1 Technical data Temposonics
®
RP5
Technical data “Electrical connection” on page 32
