Temposonics
®
R-Series V SSI
Operation Manual
I 33 I
Output
Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422)
Data format Binary or gray
Data length 8…32 bit
Data transmission rate
70 kBaud
8
…1 MBaud, depending on cable length:
Cable length < 3 m < 50 m < 100 m < 200 m < 400 m
Baud rate 1 MBd < 400 kBd < 300 kBd < 200 kBd < 100 kBd
Measured value Position
Measurement parameters
Resolution: Position 0.1…100 µm (0.0001…0.1 mm)
Resolution: Velocity 0.001 mm/s (determined over 10 measured values)
Update rate
9
Stroke length 25 mm 300 mm 750 mm 1000 mm 2000 mm 7620 mm
Update rate 10 kHz 3.4 kHz 2.7 kHz 2.1 kHz 1.2 kHz 0.3 kHz
Linearity deviation
10
Stroke length ≤ 400 mm > 400 mm
Linearity deviation ≤ ±40 μm < ±0.01 % F.S.
Optional internal linearization: Linearity tolerance (applies for the first magnet for differential measurement)
Stroke length 25...300 mm 300...600 mm 600...1200 mm
typical ± 15 µm ± 20 µm ± 25 µm
maximum ± 25 µm ± 30 µm ± 50 µm
Repeatability < ±0.001 % F.S. (minimum ±2.5 μm) typical
Hysteresis < 4 µm typical
Temperature coefficient < 15 ppm/K typical
Operating conditions
Operating temperature −40…+85 °C (−40…+185 °F)
Humidity 90 % relative humidity, no condensation
Ingress protection IP67 (connectors correctly tted)/IP68 for cable output
Shock test
150 g/11 ms, IEC standard 60068-2-27
Vibration test 30 g/10…2000 Hz, IEC standard 60068-2-6 (excluding resonant frequencies)/
RH5-J: 15 g/10…2000 Hz, IEC standard 60068-2-6 (excluding resonant frequencies)
EMC test Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
.
Operating pressure 350 bar (5,076 psi)/700 bar (10,153 psi) peak (at 10 × 1 min) for sensor rod/RH5-J: 800 bar (11,603 psi)
Magnet movement velocity Any
Design/Material
Sensor electronics housing Aluminum (painted), zinc die cast
Sensor flange Stainless steel 1.4305 (AISI 303)
Sensor rod Stainless steel 1.4306 (AISI 304L)/RH5-J: Stainless steel 1.4301 (AISI 304)
Stroke length 25…7620 mm (1…300 in.)/RH5-J: 25…5900 mm (1…232 in.)
Mechanical mounting
Mounting position Any
Mounting instruction Please consult the technical drawings on page 12 and page 13
8.2 Technical data Temposonics
®
RH5
8/ With standard one shot of 16 μs
9/ Sensor with standard settings
10/ With position magnet # 251 416-2
Technical data “Electrical connection” on page 34
