5. Affectation des connexions
1
Aileron 1
2
Gouverne de profondeur
3
Gouvernail de direction
4
Sortie des gaz
5
Aileron 2
6
Clapet 1
7
Clapet 2
1
Aileron 1
2
Empennage V 1
3
Empennage V 2
4
Sortie des gaz
5
Aileron 2
6
Clapet 1
7
Clapet 2
1
Aileron 1
2
Aileron 2
3
Gouvernail de direction (optionnel)
4
Sortie des gaz
1 6 7 5
4
3 2
4
4
1
6
1
3
2
5
7
2 3
