mycom 2016 C Series User Manual

2200LZJE-HO-C6-N_2013.12.
Chapter 3 Installation
Compound 2-stage Screw Compressor 2016**C 3.2 Installation Works
3-3
 Outer Dimensions, Weight and Lifting Position
2016LLC 2016LMC 2016LSC 2016MSC 2016SSC
Weight (kg) 1180 1140 1100 1050 1000
L (mm) 1980.5 1913.5 1842.5 1787.5 1730.5
Figure 3-1 Outer Dimensions, Weight and Lifting Position of Compressor
Photo 002 Lifting Position
