NAPCO StarLink SLE User Manual

18 StarLink
™
SLE Commercial Series Alarm Communicators -- Installation Instructions
Wiring Diagram for BACKUP Reporting Configuration
GEM-816 / GEM-P1632 / GEM-P1664, Freedom F-64 Control Panels
(+)
(–)
AUX POWER
GRN RED BRN GRAY
(CONTROL PANEL HOUSING)
1
2
3
4
5
6
7
8
9
10
11
12
13 14 15 16 17 18 19 20 21 22 26 27 28 29 23 24 25
GRAY BRN BLACK YELLOW
Control Panel PC Board
TIP RING TIP RING
TELCO PHONE
16
VAC
*For StarLink mod-
ule terminals 1 and
2: May be wired
directly to Aux
Power of the con-
trol panel when
65mA standby
current is available.
HOME
PHONES
TO TELCO
RJ31X
RING TIP
Summary of connections:
 RJ31X RED to StarLink module 10
 RJ31X GREEN to StarLink module 11
 RJ31X BROWN to Panel 28
 RJ31X GRAY to Panel 29
 Panel 27 to StarLink module 12
 Panel 26 to StarLink module 13
GRN
BLACK
RED
YELLOW
BRN
BRN
GRAY
GRAY
Optional: When Power
Supply SLE-ULPS-R is not
used, connect Panel Aux
Power to StarLink terminals
1 and 2 (observing polarity)
GRN RED
YELLOW
BLACK
*Refer to section "SUPPLYING POWER".
6 7 8 15 14 13 12 11 9 10 2* 3 4 5 1*
+12V
(–)
PGM1 PGM2 PGM3 IN1 IN2 GND IN3 RING TIP
17 16
RTS
(R)
PANEL
TX (B)
PANEL
RX (G)
CTS
Y
StarLink Radio Terminals
PANEL
RING (+)
PANEL
TIP (–)
(STARLINK RADIO HOUSING)
16VAC
Transformer
TELCO QUAD WIRE
