For information about configuring your system in MAX, open MAX and navigate to
Help»Help Topics»PXI.
Note This requires the PXI Platform Services software and Measurement &
Automation Explorer (MAX), included on your PXI Platform Services CD or your
driver CD.
Specifications
This section lists the system specifications for the following models:
• PCIe-8398 (156877x-01L)
• PXIe-8398 (156874x-01L)
• PXIe-8399 (156874x-02L)
• PXIe-8394 (156874x-04L)
Note After each model number is its specific NI assembly number in parentheses.
Ensure that the specifications of interest match the NI assembly number printed on
either the front or back side of the board.
Note x denotes all letter revisions of the assembly.
PCIe-8398 (156877x-01L) Specifications
Note These specifications are typical at 25 °C, unless otherwise stated, and are
subject to change without notice.
Physical
Dimensions 6.89 cm × 167.65 cm (2.71 in. × 6.60 in.)
Maximum cable length 3 m
Slot requirements One slot (PCI Express x16)
Compatibility Fully compatible with the PCI Express
Specification, Revision 3.0
Weight 0.147 kg (0.325 lb) typical
MXI-Express Gen-3 x16 User Manual | © National Instruments | 23
