8-14 Issue 2 December 1995
Switch Integration Device Administration
1. Press to access the SETUP menu as shown in the following
example:
2. Press to select the Advanced option. After you press the key, you see
the ADVNC screen as shown in the following example:
3. Use the left and right arrow keys to turn MWL Enhanced processing to
ON.
After you set enable MWL Enhanced processing, the SID automatically begins to
use the feature.
You do not have to save or restart the configuration. Continue to the procedure in
the next section, “Setting a Security Level.”
Setting a Security Level
The various features and functions of the SID are available only at specific
security levels. The list below shows each security level and the options available
to that level.
■ Access Level 0 — The lowest security level. The only options available to
level 0 are the ability to view integration activities, change the contrast on
the LCD display, see the software version level, and log in to other access
levels. The SID normally operates at level 0 and you do not need a
password to access level 0.
■ Access Level 1 — The second security level. Level 1 allows you to access
all level 0 features and all of the tools needed to administer the system.
The password for this level is the last five digits of your serial number.
■ Access Level 2 — The highest level of security. Level 2 allows you to
access all level 0 and level 1 features and several special diagnostic tools
available only to trained personnel. Only AT&T authorized personnel can
access this level, either on-site or remotely, to perform testing and
diagnostics on the SID. The password for this level is only given to
authorized personnel.
SETUP 1-Params 2-Ports 3-Clear
4-Advanced
ADVNC MWI Compress: OFF
<- ->1
FUNC
4
