Issue 2 December 1995 8-9
Administer Serial Data Links
Use the following instructions to check or correct the default settings.
1. To access the edit forms used to change the serial data links, press
to access the MCI MAIN MENU.
After you press the key, you see the MCI MAIN MENU as shown in the
following example:
2. Select Utils from the menu by pressing on the SID keypad.
After you press the key, you see the UTILS menu as shown in the following
example:
3. Press on the SID keypad to access the SERIAL menu.
After you press the key you see the SERIAL menu as shown in the
following example:
4. Enter the menu item number of the serial data link you need to edit.
When you select MCI or Centrex (SMDI) from the menu, you access four
edit forms. Use the forms to set the serial data to the values your
application requires. For example, press on the keypad.
NOTE:
Both the MCI and Centrex edit forms appear the same, except for
the edit form name. The MCI forms were chosen only as an
example in this document. You can select either serial data link or
both. You also can use the default values, as described earlier in
this section.
5. After you press the key, you see the BAUD RATE edit form as shown in the
following example:
NEC 1-View 2-Utils 3-System
4-Setup 5-Logs
UTILS 1-Login 2-Date/Time 3-Serial
SERIAL 1-Centrex 2-MCI
MCI Baud Rate: 1200
<- ->1
FUNC
2
3
2
