(100/104)

24.2 Emergency Contents Delete

This command is used in order to stop Emergency Contents.

1) The controller requests the monitor to set Security password.

Header Message Check code

Delimiter

SOH-'0'-Monitor ID-

'0'-'A'-'0'-'8'

STX-'C'-'A'-'1'-'F'-'0'-'0'-ETX

BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

Monitor ID: Specify the Monitor ID of which you want to change a setting.

Ex.) If Monitor ID is '1', specify 'A'.

'0' (30h): Message sender is the controller.

'A' (41h): Message type is "Command".

'0'-'8'(30h,38h): Message length (8byte)

Message

STX (02h): Start of Message

'C'-'A'-'1'-'F' (43h, 41h, 31h, 46h): Emergency Contents Command

'0'-'0' (30h, 30h): Delete

ETX (03h): End of Message

Check code

BCC: Block Check Code

Refer to the section 4.3 “ Check code” for a BCC calculation.

Delimiter

CR (0Dh): End of packet

2) The monitor replies a written in result.

Header Message Check code

Delimiter

SOH-'0'-'0'-Monitor ID-

'B'-'0'-'A'

STX-'C'-'B'-'1'-'F'-'0'-'0'-ST-ETX BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

'0' (30h): Message receiver is the controller.

Monitor ID: Indicate a replying Monitor ID.

Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.

'B' (42h): Message type is "Command reply".

'0'-'A'(30h,41h): Message length (10byte)

Message

STX (02h): Start of Message

'C'-'B'-'1'-'F' (43h, 42h, 31h, 46h): Emergency Contents Reply Command

'0'-'0' (30h, 31h): Delete

ST: Error Status

00h: No Error

01h: Error

ETX (03h): End of Message

Check code

BCC: Block Check Code

Refer to the section 4.3 “Check code” for a BCC calculation.

Delimiter

CR (0Dh): End of packet
