5.3 Set parameter
Send this message to change monitor’s adjustment and so on.
The controller requests a monitor to change value.
1
st
byte) STX: Start of Message
ASCII STX (02h)
2
nd
-3
rd
bytes) OP code page: Operation code page
This OP code page data must be encoded to ASCII characters.
Ex.) The byte data 02h must be encoded to ASCII '0' and '2' (30h and 32h).
Refer to the Operation code table.
4
th
-5
th
bytes) OP code: Operation code
This OP code data must be encoded to ASCII characters.
Ex.) OP code 1Ah -> OP code (Hi) = ASCII '1' (31h)
OP code (Lo) = ASCII 'A' (41h)
Refer to the Operation code table.
6
th
-9
th
bytes) Set value: (16bit)
This data must be encoded to ASCII characters.
Ex.) 0123h -> 1
st
(MSB) = ASCII '0' (30h)
2
nd
= ASCII '1' (31h)
3
rd
= ASCII '2' (32h)
4
th
(LSB) = ASCII '3' (33h)
10
th
byte) ETX: End of Message
ASCII ETX (03h)
STX
OP code
page
OP code
Set Value ETX
Hi
Lo
Hi
Lo
MSB
LSB
1
st
2
nd
-3
rd
4
th
-5
th
6
th
-9
th
10
th

NEC MultiSync C431 Specifications

General

Response time	6.5 ms
Display diagonal	50 \
Display brightness	400 cd/m²
Display technology	LCD
Native aspect ratio	-
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	125.73 cm
Active display area (W x H)	1095 x 616 mm
Supported graphics resolutions	800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 800, 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
USB 2.0 ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Annual energy consumption	110 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	75 W
USB version	2.0
Ethernet LAN	Yes
HDMI ports quantity	3
Compatible memory cards	MicroSD (TransFlash)
Purpose	Universal
Product type	Group video conferencing system
Product color	Black
Number of persons	- person(s)
Operating hours (hours/days)	24/7
International Protection (IP) code	IP5X, IP2X
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Orientation	Horizontal/Vertical
Certification	CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL / CSA; VCCI
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (bottom)	12.4 mm
Panel mounting interface	300 x 300 mm
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, WMV
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Number of built-in speakers	2
Megapixel	- MP
Image sensor size	- \
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth	45 mm
Width	1125 mm
Height	645 mm
Weight	16100 g
