Page #77 background imageLoading...
Page #77 background image
(77/104)
17.2 Daylight Saving Write
This command is used in order to write the setting of the Daylight Saving.
1) The controller requests the monitor to write Daylight Saving.
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'1'-'E'
STX-'C'-'A'-'0'-'1'-'0'-'1'-BM-BD1-BD2-
BT1-BT2-EM-ED1-ED2-ET1-ET2-TD-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'E'(31h, 45h): Message length (30bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'1' (43h, 41h, 30h, 31h): Daylight Saving Setting Command
'0'-'1' (30h, 31h): Write
BM: BEGIN MONTH
JANUARY DECEMBER: 01h (30h, 31h) - 12h (31h, 32h)
BD1: BEGIN DAY1
FIRST : 01h (30h, 31h)
SECOND : 02h (30h, 32h)
THIRD : 03h (30h, 33h)
FOUR : 04h (30h, 34h)
LAST : 05h (30h, 35h)
BD2: BEGIN DAY2 (Day of the week)
SUNDAY : 01h (30h, 31h)
MONDAY : 02h (30h, 32h)
TUESDAY : 03h (30h, 33h)
WEDNESDAY : 04h (30h, 34h)
THURSDAY : 05h (30h, 35h)
FRIDAY : 06h (30h, 36h)
SATURDAY : 07h (30h, 37h)
BT1: BEGIN TIME1 (Hour)
00h (30h, 30h) 23 (32h, 33h)
BT2: BEGIN TIME2 (Minute)
00h (30h, 30h) 59 (35h, 39h)
EM: END MONTH
JANUARY DECEMBER: 01h (30h, 31h) - 12h (31h, 32h)
ED1: END DAY1
FIRST : 01h (30h, 31h)
SECOND : 02h (30h, 32h)
THIRD : 03h (30h, 33h)
FOUR : 04h (30h, 34h)
LAST : 05h (30h, 35h)
ED2: END DAY2 (Day of the week)
SUNDAY : 01h (30h, 31h)
MONDAY : 02h (30h, 32h)
TUESDAY : 03h (30h, 33h)
WEDNESDAY : 04h (30h, 34h)
THURSDAY : 05h (30h, 35h)
FRIDAY : 06h (30h, 36h)
SATURDAY : 07h (30h, 37h)
ET1: END TIME1 (Hour)
00h (30h, 30h) 23 (32h, 33h)
ET2: END TIME2 (Minute)
00h (30h, 30h) 59 (35h, 39h)
TD: TIME DIFFERENCE
+01:00 : 00h (30h, 30h)
+00:30 : 01h (30h, 31h)
