12. Weekend read and write
12.1 Weekend Read
This command is used in order to read the setting of Weekend.
1) The controller requests the monitor to reply with the Date & Time.
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
STX-'C'-'A'-'1'-'A'-'0'-'0'-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to get status.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length
Message
STX (02h): Start of Message
'C'-'A'-'1'-'A' (43h, 41h, 31h, 41h):
 Weekend  command
'0'-'0' (30h, 30h): read request
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “ Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Date & Time to the controller.
Header Message Check code
Delimiter
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'C'
STX-'C'-'B'-'1'-'A'-'0'-'0'-ST-
WEEK-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller
Monitor ID: Indicate a replying Monitor ID
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply"
'0'-'C'(30h, 43h): Message length
Message
STX (02h): Start of Message
'C'-'B'-'1'-'A' (43h, 42h, 31h, 41h):
 Weekend reply  command
'0'-'0' (30h, 30h): read request
ST: Status
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
WEEK: Weekend
'0'-'0'(30h, 30h): None
bit assignment of a day of the week.
bit0: Monday
bit1: Tuesday
bit2: Wednesday
bit3: Thursday
bit4: Friday
bit5: Saturday
bit6: Sunday

NEC MultiSync C431 Specifications

General

Response time	6.5 ms
Display diagonal	50 \
Display brightness	400 cd/m²
Display technology	LCD
Native aspect ratio	-
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	125.73 cm
Active display area (W x H)	1095 x 616 mm
Supported graphics resolutions	800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 800, 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
USB 2.0 ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Annual energy consumption	110 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	75 W
USB version	2.0
Ethernet LAN	Yes
HDMI ports quantity	3
Compatible memory cards	MicroSD (TransFlash)
Purpose	Universal
Product type	Group video conferencing system
Product color	Black
Number of persons	- person(s)
Operating hours (hours/days)	24/7
International Protection (IP) code	IP5X, IP2X
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Orientation	Horizontal/Vertical
Certification	CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL / CSA; VCCI
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (bottom)	12.4 mm
Panel mounting interface	300 x 300 mm
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, WMV
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Number of built-in speakers	2
Megapixel	- MP
Image sensor size	- \
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth	45 mm
Width	1125 mm
Height	645 mm
Weight	16100 g
