12.2 Weekend Write

This command is used in order to write the setting of Weekend.

1) The controller requests the monitor to write the setting of Weekend.

Header Message Check code

Delimiter

SOH-'0'-Monitor ID-

'0'-'A'-'0'-'A'

STX-'C'-'A'-'1'-'A'-'0'-'1'-

WEEK-ETX

BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

Monitor ID: Specify the Monitor ID of which you want to change the setting.

Ex.) If Monitor ID is '1', specify 'A'.

'0' (30h): Message sender is the controller.

'A' (41h): Message type is "Command".

'0'-'A'(31h, 41h): Message length

Message

STX (02h): Start of Message

'C'-'A'-'1'-'A' (43h, 41h, 31h, 41h):



Weekend



command

'0'-'1' (30h, 30h): write request

WEEK: Weekend

'0'-'0'(30h, 30h): None

bit assignment of a day of the week.

bit0: Monday

bit1: Tuesday

bit2: Wednesday

bit3: Thursday

bit4: Friday

bit5: Saturday

bit6: Sunday

Example:

Weekend setting is “Saturday” and “Sunday”.

'2'-'0' OR '4'-'0' = '6'-'0'

ETX (03h): End of Message

Check code

BCC: Block Check Code

Refer to the section 4.3 “ Check code” for a BCC calculation.

Delimiter

CR (0Dh): End of packet

2) The monitor replies a data for confirmation.

Header Message Check code

Delimiter

SOH-'0'-'0'-Monitor ID-

'B'-'0'-'C'

STX-'C'-'B'-'1'-'A'-'0'-'1'-ST-

WEEK-ETX

BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

'0' (30h): Message receiver is the controller.

Monitor ID: Indicate a replying Monitor ID.

Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.

'B' (42h): Message type is "Command reply".

'0'-'C'(30h, 43h): Message length

Message

STX (02h): Start of Message

'C'-'B'-'1'-'A' (43h, 33h, 31h, 41h): Weekend reply command

'0'-'1' (30h, 30h): write request

ST: Status

'0'-'0'(30h, 30h): No error
