14. Serial No. & Model Name Read

14.1 Serial No. Read

This command is used in order to read a serial number.

1) The controller requests the monitor to read a serial number.

Header Message Check

code

Delimiter

SOH-'0'-Monitor ID-

'0'-'A'-'0'-'6'

STX-'C'-'2'-'1'-'6'-ETX BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

Monitor ID: Specify the Monitor ID which you want to get serial number.

Ex.) If Monitor ID is '1', specify 'A'.

'0' (30h): Message sender is the controller.

'A' (41h): Message type is "Command".

'0'-'6'(30h, 36h): Message length

Message

STX (02h): Start of Message

'C'-'2'-'1'-'6' (43h, 32h, 31h, 36h): Serial No. command

ETX (03h): End of Message

Check code

BCC: Block Check Code

Refer to the section 4.3 “ Check code” for a BCC calculation.

Delimiter

CR (0Dh): End of packet

2) The monitor replies the serial No. data to the controller.

Header Message Check code

Delimiter

SOH-'0'-'0'-Monitor ID-

'B'-N-N

STX-'C'-'3'-'1'-'6'-

Data(0)-Data(1)---Data(n)-ETX

BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

'0' (30h): Message receiver is the controller.

Monitor ID: Indicate a replying Monitor ID.

Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.

'B' (42h): Message type is "Command reply".

N-N: Message length

Note.) The maximum data length that can be returned from the monitor at a time is

32bytes.

Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).

Message

STX (02h): Start of Message

'C'-'3'-'1'-'6' (41h, 33h, 31h, 36h): Serial No. reply command

Data(0)-Data(1)----Data(n):Serial Number



The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).

Ex.) Foe example when receiveing Serial Number data 33h 31h 33h 32h 33h 33h 33h 34h

Step1: Serial Number data is encoded as character string.

Example:

33h 31h 33h 32h 33h 33h 33h 34h -> '3','1','3','2','3','3','3','4'

Step2: Decode pairs of ASCII characters to hexadecimal values.

Example:

'3','1','3','2','3','3','3','4' -> 31h 32h 33h 34h

Step3: Byte data represents the ASCII string data.

Example:

31h 32h 33h 34h -> "1234"

Result: Serial Number is "1234".
