18 • SCREENGUARD AUTOMATIC SCREEN FILTERS OPERATION INSTALLATION AND MAINTENANCE GUIDE
REPLACEMENT PARTS
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
8.3
8.1
8.2
9.1
9.2
8.2.2
8.2.3
10.1
11.1
12.1
14.1
19.2
8.2.1
18
19
8.1
20
NOTE: Substitute *** with desired mesh.
Filter Body
Filter Cover
Cover O-Ring
Stud 1/2” SS304
Washer M12 SS304
Nut 1/2“ Galvanized
Coarse Screen for 4”
Coarse Screen for 6“
Coarse Screen for 8”
Screen O-Ring
Upper Screen Adapter
Upper Screen Adapter Body
Screen Wheel
Dirt Collector Screen Bearing
Screen Only 4“ to 8”
Flushing Chamber
Flushing Chamber Body
Dirt Collector Bearing
Dirt Collector Assembly
Suction Nozzle Saddle
Hydraulic Motor
Head Collector Bearing
Hydraulic Piston
Hydraulic Piston O-Ring
Backflush Valve Galit
Repair Kit for Backflush Valve
Short Distributor
Short Distributor O-Ring
Pressure Gauge Set
Plug 1/4“ Plastic
Male Branch Tee 1/4”
Male Elbow 1/8“
Netafim Backflush Controller DCL
Aquative DCL with 1 Bracket
BSP to NPT Adapter Coupling 2”
Item Number Model Number
DescriptionKey
1
2
3
4
5
6
7
8.1
8.2
8.2.1
8.2.2
8.2.3
8.3
9
9.1
9.2
10
10.1
11
11.1
12
12.1
13
-
14
14.1
15
16
17
18
19
19.2
20
-
-
72000-009590
72000-018400
72000-008511
72000-008495
72000-104500
72000-104520
72000-018498
72000-016940
72000-092050
-
72000-018530
72000-018510
-
72000-000310
-
72000-000320
72000-018561
72000-018300
72000-018960
72000-018582
72000-018900
72000-016960
72000-015520
-
72000-018850
72000-016905
72000-017350
72000-008545
72000-019240
72000-019250
00105-006250
35500-002020
-
Not Sold Separately
Not Sold Separately
79COVERORING
27APBOLT
79WSHRM12SS304468
79ASFNUT12GALV468
79ASFCOARSESCR4
79ASFCOARSESCR6
27APCOARSCRN
79ASFSCRORING468
79ASFUPRSCRADTR468
79ASFUPRSCRADBD468
79ASFSCRWHEEL468
79ASFDCOLLSCBRG468
79ASFSCRONLY468***
79ASFFLUSHCHAM468
79BDFLUSHCHAM468
79ASFDCOLLBRNG468
79ASFDCOLL468
79ASFSCTNOZSADL468
79ASFHYDMOTOR468
79ASFHDCOLLBRNG468
79ASFHYDPISTON468
79ASFHYDPSTORNG468
79ASFBACKFLUSHVLV
61GALIL2RKIT
79ASFSHORTDIST468
79ORNGSHORTDIST468
79ASFPRESSGAUGE
79ASFPLG46810
79ASFBRANCHT14468
79ASFMALEELL18468
31NBCDCL2
61AQTVDCL1
79ASF2BSPNPTADTR
SCREENGUARD AUTOMATIC SCREEN FILTER PARTS
4”, 6” and 8“ Sizes
