1.3.2 INPUT/OUTPUT CONNECTIONS
External audio and video sources are connected to the appropriate inputs.
1. HDMI – monitor port
2. Ethernet – network connections
3. USB – connect keyboard, mouse and other peripheral devices
4. Motherboard audio connectors
5. Genlock and SDI In/Out – current generation units (designated ‘Mark M’) provide HD-BNC
connectors (High Density BNC); earlier (Mark D) units employ DIN 1.0/2.3 (Mini BNC) connectors
6. Power
SECTION 1.4 NETWORKING
Generally, simply connecting a suitable cable from one of the two Gigabit Ethernet ports on NC1 IO's
backplane is all that is required to add it to a local area network (LAN). In some settings, additional steps
may be required. You can access the system Network and Sharing control panel to accomplish more
extensive configuration tasks. If further help connecting is required, please consult your system
administrator.
