This chapter explains the layout and options of the user interface, and how to configure
NC1 IO audio and video input and output. It also introduces the various supplemental video
production features NewTek IO provides, including Proc Amps, Scopes and capture.
SECTION 2.1 THE DESKTOP
The NC1 IO default Desktop interface is shown below, and provides very useful remote monitoring options
in addition to configuration and control features.
The Desktop interface includes dashboards running across the top and the bottom of the screen. By default,
the large middle section of the Desktop is divided into quadrants, each displaying one video ‘channel’.
Beneath each channel’s viewport is a toolbar. (Note that additional viewport toolbar controls are hidden
when not in use, or until you move the mouse pointer over a viewport.)
Continue reading for an overview of the NC1 IO Desktop features.
