TECHNICAL SPECIFICATIONS
Page 54 / 76 System Manual RS Series
8 TECHNICAL SPECIFICATIONS
8.1 RS15
8.1.1 System specifications
Omni
Directional
RS15 WITH NEXO TDCONTROLLER SETUP
Frequency Response @-6 dB
35 Hz to 250 Hz
35 Hz to 150 Hz
Sensitivity 1W@1m
105 dB SPL Nominal
103 dB SPL Nominal
Peak SPL@1m
136 to 139 dB
133 to 136 dB
Available Crossover Frequencies
35-85, 35-120, 35-180 Hz
35-85 Hz
Nominal Impedance
2 x 8 Ohms
Recommended Power
1700 Watts
PRODUCT FEATURES
Component
2 x 15” long excursion neodymium 8 Ohms drivers
Height x Width x Depth
454 mm x 564 mm x 1074 mm (17.9” x 22.2” x 42.3”)
Weight: Net
52 kg (115 lb)
Connectors
2 x NL4, 4 poles connectors (1+/1- right or rear / 2+/2- left or front)
Construction
Baltic Birch Plywood & structured black coating
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
SYSTEM OPERATION
Recommended powering solution
NXAMP4x4mk2 Powered TD controller:
2 x RS15 in omni mode (drivers in //) per channel
4 x RS15 in directional mode: 2 channels
Optional powering solution
NXAMP4x2mk2 Powered TD controller:
1 x RS15 in omni mode (drivers in //) per channel
NXAMP4x1mk2 Powered TD controller (Bridged):
1 x RS15 in omni mode (drivers in //) per bridged channels

Nexo Ray Sub Series Specifications

General

Brand	Nexo
Model	Ray Sub Series
Category	Subwoofer
Language	English
