Nexo Ray Sub Series System Manual

TECHNICAL SPECIFICATIONS
System Manual RS Series Page 59 / 76
8.2 RS18
8.2.1 System specifications
Omni
Directional
RS18 WITH NEXO TDCONTROLLER SETUP
Frequency Response @-6 dB
29 Hz to 250 Hz
29 Hz to 150 Hz
Sensitivity 1W@1m
105 dB SPL Nominal
103 dB SPL Nominal
Peak SPL@1m
143 to 146 dB
140 to 143 dB
Available Crossover Frequencies
30-60, 30-85, 30-120 Hz
30-60, 30-85 Hz
Nominal Impedance
2 x 8 Ohms
Recommended Power
2500 Watts
PRODUCT FEATURES
Component
2 x 18” long excursion neodymium 8 Ohms drivers
Height x Width x Depth
520 mm x 1403 mm x 732 mm (20.46” x 55.24” x 28.81”) with handles
520 mm x 1238 mm x 732 mm (20.46” x 49.92” x 28.81”) without handles
Weight: Net
105 kg (231.5 lb) with handles
90 kg (199 lb) without handles
Connectors
2 x NL4, 4 poles connectors (1+/1- right or rear / 2+/2- left or front)
Construction
Baltic Birch Plywood & structured black coating
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
SYSTEM OPERATION
Recommended powering solution
NXAMP4x4mk2 Powered TD controller:
1 x RS18 in omni mode (drivers in //) per channel
2 x RS18 in directional mode: 2 channels
Optional powering solution
NXAMP4x1mk2 Powered TD controller (Bridged):
1 x RS18 in omni mode (drivers in //) per bridged channels
