7
6
8
9
Shows icons such as signal strength,
GPS strength, recording status,
and processes.
Display
6
Records the vehicle interior.
Interior camera
7
iQ sounds will emit from here.
Speaker
8
Records sound for video and
listens for voice commands.
Microphone
9
Remove the red cover to expose adhesive
pad beneath. This pad is pressed onto the
rear window to mount the Rear Camera.
Adhesive Pad
12
Records the road behind the vehicle.
Rear Camera
13
Press to protect the current video file.
Protect Button
10
Measures the light level to decide
when to switch between day and
night recording.
Light Sensor
11
4
Connect Power and Rear Cam Cable.
Connectors
5
Remove the red cover to expose adhesive
pad beneath. This pad is pressed onto
the windscreen to mount the iQ.
Adhesive Pad
Records the road in front.
Front Camera
1
SD card slot.
Dust Cover
2
Connects iQ to the 4G network, allowing you
to access iQ videos and Live View remotely.
These are fragile, be careful when handling.
4G Antennae
3
12
5
1
2
3
4
11
10
13
8
CAMERA PARTS
To Next Page
