Connecting the cooling circuit
■
Use the flare method to connect the pipes.
■
Keep all pipework as short as possible.
■
Lubricate the contact surfaces and hand tighten, then
tighten the connections using a torque wrench to ob-
tain a good and secure connection. See the installation
instructions on page 15.
■
Check carefully that there is no risk of any leakage
prior to the function test.
Connections
Caution
The hot water module is connected AG-DW10 to the marked AG-DW10 port.
Indoor unit
Indoor units with last number -4Size A
Indoor units with last number -7Size B
AG-AC10-65 + one indoor unit
AG-DW10
Size B
AG-DW10 port: for connection refer to the Installer Manual for AG-DW10
AG-AC10Chapter 3 | Pipe connections8
