Nibe F1145 series User Manual

Technical specifications
3X230 V
F1145-17F1145-15Model
Output data according to EN 14511
0/35 nominal
16.7815.33kWHeating capacity (P
H
)
3.903.47kWSupplied power (P
E
)
4.304.42COP
0/45 nominal
16.1714.92kWHeating capacity (P
H
)
4.524.11kWSupplied power (P
E
)
3.583.63COP
SCOP according to EN 14825
20 / 2018 / 18kWRated heating output (P
designh
)
4.5 / 3.74.7 / 3.7SCOP cold climate, 35 °C / 55 °C
4.4 / 3.64.6 / 3.7SCOP average climate, 35 °C / 55 °C
Energy rating, average climate
A++ / A++A+++ / A++The product's room heating efficiency class 35 °C / 55 °C
1
A++ / A++A+++ / A++The system's room heating efficiency class 35 °C / 55 °C
2
A / XXL
(VPB500)
A / XXL
(VPB500)
Efficiency class hot water heating / declared tap profile with water heater
3
Noise
4242dB(A)Sound power level (L
WA
)
EN 12102
at 0/35
2727dB(A)
Sound pressure level (L
PA
) calculated values according to EN ISO 11203 at 0/35 and 1 m range
Refrigerant circuit
R407CType of refrigerant
1,774GWP refrigerant
2.02.0kgFill amount
3.553.55tonCO
2
equivalent
2.9 (29 bar) / 0.15 (1.5 bar)MPaCut-out value pressure switch HP / LP
Brine circuit
0.05 (0.5 bar) / 0.3 (3 bar)MPaMin/max system pressure brine
0.670.62l/sMin flow
0.820.75l/sNominal flow
4858kPaMax external avail. press at nom flow
see diagram°CMin/Max incoming Brine temp
-12°CMin. outgoing brine temp.
Heating medium circuit
0.05 (0.5 bar) / 0.4 (4 bar)MPaMin/Max system pressure heating medium
0.270.25l/sMin flow
0.400.36l/sNominal flow
5560kPaMax external avail. press at nom flow
see diagram°CMin/max HM-temp
Pipe connections
3528mmBrine ext diam. CU pipe
2828mmHeating medium ext diam. CU pipes
2828mmConnection, hot water heater ext diam
Dimensions and weight
600 x 620 x 1,500mmWidth x Depth x Height
1,670mmCeiling height
4
205200kgWeight complete heat pump
136134kgWeight only cooling module
Lead in brass componentsSubstances according to Directive (EG) no. 1907/2006, article 33 (Reach)
065 459065 140Part number, 3x230 V
1
Scale for the product’s efficiency class room heating: A+++ to D.
2
Scale for the system’s efficiency class room heating: A+++ to G. Reported efficiency for the system takes the product’s temperature
regulator into account.
3
Scale for efficiency class hot water: A+ to F.
4
With feet removed, the height is approx. 1,650 mm.
75Chapter 12 | Technical dataNIBE F1145
