Control
FIGHTER 1210
For the Installer
12
Settings
DriftP
Shows the status of the operating pressostat (1
= closed, 0 = open).
HP/MS
Shows the status of the high pressure presso-
stat/motor protection (1 = closed, 0 = open).
Gives a permanent alarm. Manual resetting of
the motor protection.
LP
Shows the status of the low-pressure pressostat
(1 = closed, 0 = open). Gives a permanent alarm.
68: Start contactor, HP
69: Operating contactor, HP
35: Brine pump
XX: Reversing valve hw
16: Heating medium pump
L: Not active
x1: Supplement 1
x2: Supplement 2
x3: Not active
Brine-pump
Positive operation of brine pump. Change 0 to 1
using the Increase button at the same time as
pressing the Operating mode button. 1 is then
replaced by KB. Return to normal mode after 10
days or with a restart.
Add-drift
For just electric boiler operation (e.g. before col-
lector installation is complete), toggle 0 to 1 and
press the Mode button”. The 1 is then supple-
mented with “EP.
Option 2 – 5 may not be used.
Select the right operating mode before Add-drift
is activated. ((Add-drift locks the operating mode
function).
Man:Manual test of outputs. Change Man 0 to Man 1
or Man 2 to test different functions. Man 0 must be set
before you can exit the menu.
Servicetime
Change from 0 to 1 to speed up the period of
time by 60 times. Resets 8 minutes after the last
button was pushed.
Parallel
Setting of Increase/Reduce heat potentiometer
to displace the heating curve (parallel offset).
12
13
14
15
16
XWW-stop
[P] Extra hot water stop temperature.
Basic setting: 65.
Setting range: 60 – 65.
XWW-int
[P] Interval in days for periodic extra hot water.
Basic setting: 14.
Setting range: 1 – 90.
Cal. Out
[P] Calibration of outside sensors.
Room
[P] Calibration of room sensor.
Brine In
[P] Calibration of brine flow sensor.
Brine Out
[P] Calibration of the brine return sensor.
Setting values for all quantities: -5 – +5.
17
Operating mode button
XWW-stop 65 °C
XWW-int 14d
DriftP 1
HP/MS 1LP 1
Brine-pump 0
Add-drift 0
Cal.Out 0Room 0
BrinIn 0BrinO 0
Man 0
Man: 1 68 0 69 0
35 0 XX 0
Servicetime 0
Parallel 0
Man: 2 16 0 L 0
x1 0 x2 0 x3 0
