Nibe MODBUS 40 User Manual

Communication
TIP
ModbusManager can be downloaded via
www.nibe.se/kommunikation.
Read the values
There are two ways of reading the values from the heat
pump/indoor module, automatically or manually.
■
Automatic reading: can retrieve up to 20 predefined
parameters at the same time.
■
Manual reading: takes longer and only one value at
a time can be retrieved.
Automatic reading
Caution
Maximum 20 parameters defined in the
LOG.SET file can be used by MODBUS 40 (cor-
responds to 20x16-bits Modbus-register). If
more parameters are selected, the first 20
parameters are used.
A small number of parameters are 32-bit, and
therefore take up two registry locations, which
means that fewer parameters can be read.
1.
Create a LOG.SET file that contains the predefined
values that are to be read out. The file is created
in ModbusManager. See section "Create a log set-
tings file in ModbusManager" for instructions.
2.
Save LOG.SET to a USB-memory.
3.
Insert the USB-memory into the heat pump's/in-
door module's display unit.
4.
Enter menu USB.
5.
Enter menu "logging".
6.
Tick “activated".
7.
Remove the USB-memory.
The heat pump/indoor module will now update the
values for all defined parameters twice a second.
Retrieve the values for the Modbus-master by using
the "Read holding registers" command with the desired
parameter addresses. Use ModbusManager, see
LOG.SET in a text editor or see the examples list on
page 19 to see which parameter address a value has.
See section The Modbus command on page 19 for
further information about different commands.
17
GB

Nibe MODBUS 40 Specifications

General

Category	Control Unit
Communication	RS485
Communication protocol	Modbus RTU
Data bits	8
Parity	None, Even, Odd
Stop bits	1, 2
Connection type	Screw terminal
Power supply	24 V AC/DC
Protection class	IP20
Relative humidity	5% to 95% (non-condensing)
Storage temperature	-40°C to +70°C
