Nikon D3100 User Manual

188
n
Troubleshooting
If the camera fails to function as expected, check the list of common problems below
before consulting your retailer or Nikon representative.
Display
Shooting (All Modes)
Viewfinder is out of focus: Adjust viewfinder focus or use optional eyepiece correction lenses
(0 22, 176).
Displays turn off without warning: Choose longer delays for Auto off timers (0 143).
Information display does not appear in monitor: Shutter-release button is pressed halfway. If
information display does not appear when you remove your finger from shutter-release
button, confirm that On is selected for Auto info display (0 139) and that battery is charged.
Camera does not respond to controls: See “A Note on Electronically-Controlled Cameras,” below.
Viewfinder display is unresponsive and dim: The response times and brightness of this display vary
with temperature.
A A Note on Electronically-Controlled Cameras
In extremely rare instances, unusual characters may appear in the monitor and the camera
may stop functioning.
In most cases, this phenomenon is caused by a strong external static
charge.
Turn the camera off, remove and replace the battery, taking care to avoid burns, and
turn the camera on again, or, if you are using an AC adapter (available separately), disconnect
and reconnect the adapter and turn the camera on again.
If the problem persists after
removing the battery from the camera, contact your retailer or Nikon-authorized service
representative.
Camera takes time to turn on: Delete files or folders.
Shutter-release disabled:
• Memory card is locked, full, or not inserted (0 20, 24).
• Built-in flash is charging (0 27).
• Camera is not in focus (0 26).
• CPU lens with aperture ring attached but aperture not locked at highest f-number (0 168).
• Non-CPU lens is attached but camera is not in mode M (0 169).
Final photo is larger than area shown in viewfinder: Viewfinder horizontal and vertical frame coverage
is approximately 95%.
Photos are out of focus:
• AF-S or AF-I lens is not attached: use AF-S or AF-I lens or focus manually.
• Camera unable to focus using autofocus: use manual focus or focus lock (0 60, 62).
• Camera is in manual focus mode: focus manually (0 62).

Nikon D3100 Specifications

General

Megapixel	14.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Image sensor size	- \
Maximum image resolution	4608 x 3072 pixels
Image sensor size (W x H)	23.1 x 15.4 mm
Still image resolution(s)	-
Digital zoom	- x
Focal length range	- mm
Interface	USB
Digital SLR	Yes
Power source type	Battery
Dimensions (WxDxH)	124 x 96 x 74.5 mm
Camera shutter speed	1/4000 - 30 s
Effective sensor resolution	14800000 pixels
Auto focusing (AF) modes	Single Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Field of view	95 %
Display diagonal	3 \
Display resolution (numeric)	230000 pixels
Magnification	0.8 x
USB version	2.0
Scene modes	Children, Close-up (macro), Portrait
Photo effects	Black&White
White balance	Auto, Manual
Self-timer delay	10 s
Product color	Black
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s

Weight and Dimensions

Depth	96 mm
Width	124 mm
Height	74.5 mm
Weight	505 g
