Nikon TIRF User Manual

IV Shutter Control Unit Communications Commands
1 Communication-controlled operation
- 29 -
IV
IV
Shutter Control Unit Communications
Commands
1 Communication-controlled operation
You can control this system from your PC or other devices through the RS-232C interface.
Create your own control program based on the information given in this manual.
1-1 Communications system
Start-stop serial communication
1-2 Connector specification
The following signals are used with the system's serial interface connector:
D-sub 9-pin connector (male)
Pin No. Signal I/O
1 Unused -
2 RxD Input
3 TxD Output
4 Unused -
5GNDGND
6 Unused -
7 Unused -
8 Unused -
9 Unused -
