Nokia FastMile 4G Receiver Installation Guide Inserting the SIM card in the Nokia FastMile 4G
Receiver
Issue: 01 3TG-00387-ABBA-TCZZA 43
9.2 Inserting the SIM card
Although the following procedure provides instructions for inserting a SIM card in the
Nokia FastMile 4G Receiver, you should contact your Nokia representative for more
detailed information.
Procedure 5 To insert the SIM card in the Nokia FastMile 4G Receiver
1 Use a TORX T8 screwdriver to remove the cover from the SIM card slot of the Nokia FastMile
4G Receiver.
2 Insert a valid Nano/4FF SIM card in the SIM card slot, with the bottom of the SIM card facing
you as shown in Figure 8.
Figure 8 shows the orientation for inserting the SIM card in the SIM card slot of the Nokia
FastMile 4G Receiver.
Figure 8 Orientation of the SIM card
For the Compact mono-band and ABA models, insert the SIM card in the correct orientation
using your fingers, and then for Compact mono-band models, use the SIM card tool (“nipple”)
supplied with the Nokia FastMile 4G Receiver to carefully push the SIM card all the way in.
Keep the SIM card tool in case it is needed later to extract the SIM card.
Warning — To avoid the possibility of a short circuit, make sure
that the Nokia FastMile 4G Receiver is in a powered off state
before inserting the SIM card.
Warning — If the SIM card needs to be replaced later on, the
Nokia FastMile 4G Receiver needs to be put in a powered off
state before you extract the SIM card and insert the new one.
