Nokia FastMile 4G Installation Guide

Mounting and connecting the Nokia FastMile 4G
Receiver
90
Nokia FastMile 4G Receiver Installation Guide
3TG-00387-ABBA-TCZZA Issue: 01
Figure 48 Attaching the mounting plate to the Nokia FastMile 4G Receiver
5 As appropriate, drill a hole through the wall for the Ethernet cable to be able to pass through.
It is recommended that you drill the hole for the Ethernet cable at a slight angle so that any
water that might enter the hole will run down towards the outside of the home.
6 If you are wall-mounting the Nokia FastMile 4G Receiver, drill two anchor holes as
appropriate for the receiver bracket on the outside of the wall. The anchor holes should be
one directly above the other. You can use the receiver bracket as a template for the anchor
holes.
7 If you are wall-mounting the Nokia FastMile 4G Receiver, attach the receiver bracket to the
outside of the wall using two appropriate fasteners in the anchor holes drilled in the previous
step, as shown in Figure 49. Ensure that the receiver bracket is in a vertical position on the
wall.
28801
Install the
screws
