Nokia G-2425G-B User Manual

5
DANGER
Hazard
Fiber cables transmit invisible laser light. To avoid eye damage or blindness, never look directly
into fibers, connectors, or adapters.
WARNING
Equipment Damage
Be careful to maintain a bend radius of no less than 1.5 in. (3.8 cm) when connecting the fiber
optic cable. Too small of a bend radius in the cable can result in damage to the optic fiber.
Connect the fiber optic cable with SC/APC adapter to the SC/APC connector on the bottom of
the ONT.
Note: Fiber cable preparation varies depending on the type and size of the inside or
outside plant fiber cable being spliced to the SC/APC fiber optic pigtail cable.
6
Connect the power cable to the power connector.
7
Power up the ONT unit by using the power switch.
8
If used, enable the Wi-Fi service.
a. Locate the WLAN button on the ONT; see Figure 5-1, “G-2425G-B ONT connections” (p. 61)
for location of the WLAN button.
b. Press the WLAN button to change the status of the Wi-Fi service.
9
Verify the ONT LEDs, voltage status, and optical signal levels; see the 7368 Hardware and
Cabling Installation Guide.
10
Activate and test the services; see the 7368 Hardware and Cabling Installation Guide.
11
If used, configure the SLID; see the 7368 ISAM ONT Configuration, Management, and
Troubleshooting Guide.
Install a G-2425G-B indoor ONT
Procedure
7368 ISAM ONT
Draft Draft
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
August 2020
62 Issue 4

Nokia G-2425G-B Specifications

General

Model	Nokia G-2425G-B
Wi-Fi Standards	802.11a/b/g/n/ac
Frequency Band	2.4 GHz, 5 GHz
Ethernet Ports	4 x Gigabit Ethernet
Antennas	Internal
Security	WPA3, WPA2, WPA
Power Supply	12 V DC
