Parts list
Mechanical spare parts list
Note: For Nokia product codes, please refer to the latest Service Bulletins on the Partner Website (PWS).
To ensure you are always using the latest codes, please check the PWS on a daily basis.
"*" = Spare part can not be reused after disassembly.
ITEM/CIRCUIT
REF.
QTY SPARE PART DESCRIPTION EUROPE MEA APAC CHINA
I0001* 1 A-COVER
I0001* 1 A-COVER ASSY X X X X
I0002 1 KEYMAT
I0002 1 KEYMAT STROKE S X X
I0002 1 KEYMAT LATIN X X X
I0002 1 KEYMAT THAI X
I0002 1 KEYMAT STROKE X
I0002 1 KEYMAT HINDI X
I0002 1 KEYMAT GUJARATI X
I0002 1 KEYMAT BENGALI X
I0002 1 KEYMAT PUNJABI X
I0002 1 KEYMAT TAMIL X
I0002 1 KEYMAT TELUGU X
I0002 1 KEYMAT KANNADA X
I0002 1 KEYMAT MALAYALAM X
I0002 1 KEYMAT HEBREW X
I0002 1 KEYMAT GREEK X
I0002 1 KEYMAT CYRILLIC X
I0002 1 KEYMAT ARABIC X X
I0002 1 KEYMAT URDU X
I0002 1 KEYMAT FARSI X
I0002 1 KEYMAT BOPOMOFO X X
I0002 1 KEYMAT SINHALA X
I0003 6 SCREW M1.8X6 TORX PLUS X X X X
I0004 1 UI SHIELD ASSEMBLY X X X X
I0005 1 LCD MODULE X X X X
A1 1 2CB LIGHT SWAP PACKAGE (I0006 -
I0014)
I0006* 1 DOMESHEET X X X X
RM-237
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –7
Copyright © 2007 Nokia. All rights reserved.
