ITEM/CIRCUIT
REF.
QTY SPARE PART DESCRIPTION EUROPE MEA APAC CHINA
A4 1 C-COVER ASSEMBLY X X X X
I0032 1 C-COVER
I0033 1 RELEASE BUTTON
Component parts list (2cba_31a)
Item ref PWB side X Y Description and value
A2200 Bottom K 4 RETU TAHVO SHIELD ASSY
A2400 Bottom T 3 FLEX SHIELD FRAME
A2800 Bottom K 7 RAP_MEM SHIELD ASSY
A3300 Bottom O 8 HW_ACC ASSEMBLY
A6000 Bottom Q 2 BT SHIELD ASSY
A6100 Bottom H 7 FM SHIELD ASSY
A7000 Bottom R 6 RF ASSEMBLY
B2100 Bottom B 8 CLAPTON EMC MICROPHONE MOD -4
B2101 Bottom T 7 EARP RDF-07A 32OHM 10.86x7.40
B2200 Bottom M 3 CRYSTAL 32.768KHZ +/-30PPM 12
C2000 Bottom A 4 CHIPCAP NP0 27P J 50V
C2001 Bottom B 4 CHIPCAP X5R 470N K 25V
C2002 Bottom B 3 CHIPCAP X7R 10N K 50V
C2008 Bottom C 3 CHIPCAP X7R 1N0 K 50V
C2030 Bottom E 5 CHIPCAP NP0 270P J 50V
C2031 Bottom E 5 CHIPCAP X7R 1N0 K 50V
C2032 Bottom D 5 CHIPCAP X7R 10N K 16V
C2033 Bottom E 5 CHIPCAP X7R 33N K 10V
C2034 Bottom E 5 CHIPCAP X7R 33N K 10V
C2035 Bottom C 6 CHIPCAP NP0 27P J 50V
C2040 Bottom H 6 CHIPCAP X5R 2U2 K 6V3
C2041 Bottom C 4 CHIPCAP X5R 2U2 K 6V3
C2042 Bottom D 4 CHIPCAP X7R 1N0 K 50V
C2043 Bottom C 4 CHIPCAP X7R 1N0 K 50V
C2044 Bottom C 5 CHIPCAP NP0 18P J 50V
C2045 Bottom D 5 CHIPCAP NP0 18P J 50V
C2046 Bottom C 4 CHIPCAP X5R 100N K 16V
C2047 Bottom C 4 CHIPCAP X5R 4U7 K 6.3V
RM-237
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –9
Copyright © 2007 Nokia. All rights reserved.
