Item ref PWB side X Y Description and value
S2401 Bottom O 2 SM SW TACT SPST 12V SIDE KEY
S2402 Bottom S 2 SM SW TACT SPST 12V SIDE KEY
S2403 Top U 5 SM SW TACT SPST 12V SIDE KEY
T7501 Bottom R 4 TRANSF BALUN 3800 +/- 550MHZ
T7520 Bottom S 9 TRANSF BALUN 1800+-100MHZ 2X
V2000 Top B 4 ASIP TVS BGA4
V2405 Top G 4 LED WHITE 140MCD 5MA
V2406 Top G 7 LED WHITE 140MCD 5MA
V2407 Top B 7 LED WHITE 140MCD 5MA
V2409 Top B 4 LED WHITE 140MCD 5MA
X1001 Bottom U 3 CONN BTB 2X12 F P0.4 30V 0.2A
X2000 Bottom A 7 CONN CHR DIA 2.0MM COMPRESS
X2002 Bottom B 3 CONN USB 5POL MINI-USB B TYPE
X2030 Bottom B 5 SMD CONN AUD/VID 4POL 30V 2A,
X2060 Top A 4 MODULE ID COMPONENT 2.8X1.8X0
X2070 Bottom O 3 SM BATTERY CONN 3POL SPR 12V
X2700 Bottom G 3 CONN SIM SM 6POL P2.54 H1.05
X3200 Bottom E 8 CONN MICRO SD HINGE
X3300 Bottom P 5 SMIA85 SOCKET
X7000 Bottom T 8 SM CONN RF JACK 50R 2W 6GHZ
Z2001 Bottom C 3 FERRITE BEAD 0.6R 600R/100MZ
Z2400 Bottom H 4 ASIP 10-CH LCD FILTER W/ESD B
Z2401 Top U 4 ASIP 7-CH LCD FILTER W/ESD BG
Z2402 Bottom R 2 ASIP 7-CH LCD FILTER W/ESD BG
Z2700 Bottom H 3 ASIP SIM ESD/EMI FILT 400UM B
Z6030 Bottom R 2 LTCC FILT 2441.75+-41.75MHZ
Z7001 Bottom T 8 PHASESHIFTER-60°@1850 GSM850.
Z7002 Bottom T 9 PHASESHIFTER-60°@1850 GSM850.
Z7501 Bottom S 7 DUAL RX SAW FILTER 1800/1900
Z7503 Bottom Q 7 SAW MODULE TX GSM 850/900MHz
Z7504 Bottom R 7 DUAL RX SAW FILTER 850/900 MH
Z7520 Bottom S 8 FERRITE BEAD 0R01 28R/100MHZ
Swap units
Table 7 Swap phones
Note: For product codes, please refer to the latest Service bulletin.
RM-237
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –21
Copyright © 2007 Nokia. All rights reserved.
