Notifier ACM-16AT User Manual

NFS-3030 Systems
PN 15842:K 7/23/2002 93
V.7 ACS Program Mapping
ACS points “track” or follow those system points they are programmed to
annunciate; the annunciator points do not latch. Table P-1, which follows, lists
how the ACS annunciates various devices and functions.
Note: Control Switches marked “not used” will still function as local LAMP TEST
switches for their respective LEDs.
*With the NFS-3030, the functions of ACKNOWLEDGE, SIGNAL SILENCE, SYSTEM
RESET and LAMP TEST may be assigned (mapped) to multiple annunciator points.
Point Type
ACM-24AT or ACM-16AT Module and
AEM-24AT or AEM-16AT Expanders
ACM-48A or
ACM-32A Module &
AEM-48A or
AEM-32A Expander
Active LED Trouble LED Control Switch
Control Module
XPC Circuit
XPR Circuit
XPIQ Speaker and
Telephone/Strobe Circuits
XP5-C Circuit
Indicates on/off status
of module or circuit
Indicates trouble
status of module or
circuit
Turns module on/off
Monitor Module
XPM Circuit
Indicates alarm status
of module or circuit
Indicates trouble
status of module or
circuit
Not used
Intelligent Detector Indicates alarm status
of detector
Indicates trouble
status of detector
Not used
Logic Zone Indicates active status
of logic zone
Not used Not used
ACKNOWLEDGE
*
Indicates System
Alarm
Indicates System
Trouble
ACKNOWLEDGE key
SIGNAL SILENCE
*
Not used Indicates Signals
Silence
SIGNAL SILENCE
key
SYSTEM RESET
*
Not used Not used SYSTEM RESET key
LAMP TEST
*
Not used Not used LAMP TEST key
Table V-1 Annunciator Program Mapping with NFS-3030
