4. Read Status Operation Viewing and Printing a Read Status
46 NFS-640 Operations Manual P/N 51334:B 10/03/2003
How to View Read Status for a NAC or Panel Circuit
From the “Read Status” screen, press 0, then press the
ENTER key.
You can now view Read Status for a NAC or Panel Circuit as
follows: press
OUTPUT, enter the device address, then press the
ENTER key. For example, to read the status of NAC 0-2: press
OUTPUT, enter 02, then press the ENTER key. The control panel now
displays information for a NAC as shown in Figure 23.
The display and descriptions of the fields are shown below:
Figure 23 Sample NAC & Panel Circuit Read Status Display
• Device Status The status of the device: ON (device active) OFF (device not active).
• Type Code The software Type Code that identifies the type of NAC or Panel Circuit. Refer to
“Appendix F - Type Codes” in NFS-640 Programming Manual.
• CBE List Only the first zone in the NAC or Panel circuit’s CBE list will be displayed here.
• Device Address The address of the NAC (01-04) or Panel Circuit (1-1 - 8-8)
• Switch Inhibit A selection for disabling the switch function for the panel circuit, control/relay,
or transponder output circuit. (I=on; *=off).
• Silenceable A selection that specifies if the device can be silenced during an alarm by pressing
the
SIGNAL SILENCE key.
• Walk Test A selection that specifies if the device will activate during a Walk Test.
Device address
next device
previous device
Type Code (CONTROL)
Walk Test selection:
W selected for Walk Test
* not selected
Label for the NAC or Panel Circuit
Default zone selection
Address (01-04)
B = NAC
P = Panel Circuit
Switch Inhibit: I selected, * not selected
Device status
Silenceable: S selected (default), * not selected
OFF CONTROL PANEL CIRUIT NO. 2
Z000 *SW B02
