SFP-400B 15124:G1 06/24/97
19
3.6 Optional Modules
This fire control panel has two module connectors - J5 and J8. Three modules are available for the panel
and they can be used in any combination, including duplicate modules (see notes below). The
corresponding option jumper must be cut before installation of an optional module, to enable module
supervision.
Notes: Optional 4XLM module for an RZA-4X Annunciator must be installed on J7 and J8 only.
4XTM and 4XZM modules can be installed in either location.
Battery Power
Observe polarity when connecting battery. Connect battery cable to J9 on the main board using the plug-
in connector provided. See Appendix A for calculation of correct battery rating.
CAUTION: Batteries contain sulfuric acid which can cause severe burns to the skin
and eyes, and can destroy fabrics. If contact is made with sulfuric acid, immediately
flush skin or eyes with water for 15 minutes and seek immediate medical attention.
OPT1 Jumper
Cut to install module
on J5.
OPT2 Jumper
Cut to install module
on J8.
Figure 3.6-1: Option Panel Modules
