NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 16 -
Approximate damping times
FL = 30 seconds
90% = 9 seconds
80% = 8 seconds
70% = 7 seconds
60% = 6 seconds
50% = 5 seconds
40% = 4 seconds
30% = 3 seconds
20% = 2 seconds
10% = 1 second
0% = instantaneous
___________________________
Section 5 Presets
The DS dimmer has the capacity for 400 presets with time fade. The first 12 presets correspond to the analog
submasters described in section 5. The remainder of the presets, termed "deep presets" are capable of being started
manually from the front panel, or triggered by an analog input channel. These 388 deep presets feature 0 to 999.9
second dipless cross fade times, and hold times of between .1 to 999.9 second or forever. These deep presets can
also be linked, so that a chase effect can be created. This section has been divided into three sub sections, Editing
deep presets, running deep presets, and analog triggered deep presets
5.1 Editing Deep Presets
From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [PRESET#] keypad. The following menu will be displayed:
PRESET # = 01
[EDIT] [RUN]
Type in the preset # you wish edit. Note that presets 1 through 12 are analog submaster scenes. For convenience, lets
choose Preset# 020. Then press [EDIT]. The following menu will be displayed:
DIMMER=01 AT FL
PRESET=020[MORE]
Edit the dimmer control levels you wish to see in the preset. If you wish to edit the control level for channel 1, press
[ENTER]. If you wish to edit the control level of another channel, enter the dimmer number, or press [ENTER]
until the dimmer # you desire appears in the window. Note that [ENTER] steps the menu to the next entry field, or
auto increments to the next dimmer channel. [CLEAR] steps back one field or menu, each time it is pressed. Note
that you cannot change the preset # from this sub menu, although the preset you are editing is displayed in the lower
left corner of the LCD screen. When you are finished editing levels, press [MORE]. The following menu will
appear:
FADE TIME = 000.0s
[MORE]
Set the dipless cross fade time that you wish for this preset to fade in. The previous preset will fade out at the same
rate. A 000.0second fade time fades instantaneously. A 999.9second fade time fades out in 16- 2/3 minutes. Press
[MORE] when you are finished. The following menu will be displayed:
HOLD TIME = 000.0s
[MORE]
