Octave HP 300 MK2 User Manual

25
13. SPECIFICATION
Features
 The HP 300 MK2MKII is fitted as standard with two cinch outputs, one XLR output and
one XLR input.
 Gain of the line amplifier and the phono board also is switchable to adjust the overall
gain of the preamplifier - amplifier combination
 An optional phono MC module may be added any time.
 MC input impedance is adjustable over a wide range.
 Soft-start for heaters, operating voltage and signal output. This results in maximum
service life of the tubes and noise-free switch-on/off. The output is enabled after 4
minutes.
Diagrams
Overall distortion (THD + noise) of line stage from 20 Hz - 200 kHz.
Distortion remains low up to 20 kHz
Frequency response accuracy of line stages in 'low gain'
setting. 20 Hz - 200 kHz: 0.1 dB

Octave HP 300 MK2 Specifications

General

Brand	Octave
Model	HP 300 MK2
Category	Amplifier
Language	English
