Octave HP 700 User Manual

CONNECTIONS
HP 700 rear panel
11
CONNECTIONS
HP 700 rear panel
Legend
(5) GND connection
Ground connection for phono
(6) IN 1 SL1
Slot for a phono or line input module
(7) IN 2 SL2
Slot for a phono or line input module
(8) IN 5 RCA input
Line-level input for CD, tuner, etc.
(9) IN 3 XLR input
Balanced line-level input for CD, DAC, etc.
(10) IN 6 RCA input
Line-level input for CD, tuner, etc.
(11) IN 7 RCA input
Line-level input for CD, tuner, etc.
Note
On the connector panel, the bottom row of sockets (red) is the right channel, while the
top row of sockets (white) is the left channel.
