Octave HP 700 User Manual

TECHNICAL DATA
In- and outputs
31
TECHNICAL DATA
In- and outputs
In- and outputs
Inputs
3 x RCA, 2 x XLR, 2 x arbitrary
1 x RCA bypass (can be switched to IN4-XLR)
Outputs
2 x RCA, 1 x XLR, 1 x Monitor/Tape Record (RCA)
XLR transmission ratio
0 dB
XLR pin assignment
1 = ground, 2 = positive, 3 = negative
Line stage
Output resistance
100/300 ohms RCA; 150 ohm XLR
Monitor Out output resistance
240 ohms
Maximum output voltage
12 V
Gain factor – Gain High
25 dB = 18.5
Gain factor – Gain Med
18 dB = 7.8
Gain factor – Gain Low
12 dB = 4
Signal-to-noise ratio – Gain High
-98 dB/38 µV at 3 V output voltage
Signal-to-noise ratio – Gain Med
-104 dB/18 µV at 3 V output voltage
Signal-to-noise ratio – Gain Low
-110 dB/8 µV at 3 V output voltage
Equivalent noise level
14 nV  Hz
Frequency range – Gain High, RCA
10 Hz – 200 kHz -0.7 dB / 0.7 MHz -6 dB
Frequency range – Gain Med, RCA
10 Hz – 200 kHz -0.3 dB / 1.3 MHz -6 dB
Frequency range – Gain Low, RCA
10 Hz – 200 kHz -0.2 dB / 2.1 MHz -6 dB
Frequency range – XLR
10 Hz – 200 kHz -1.5 dB
Ramp-up time – Gain Low
250 ns
Ramp-up speed – Gain Low
60 V/µs
Total harmonic distortion – Gain Low,
Med, High
0.01 % at 3 V on 10 kohm
Channel separation
-90 dB/1 kHz, input short-circuited
Crosstalk between inputs
-80 dB/RCA, -95 dB XLR/1 kHz
Input resistance
50 kohm
Channel matching via volume control
0.5 dB – 70 dB
