Network User’s Guide
60
9. When the settings are correct, click Execute. The new
settings are transmitted to the network interface but it
still operates with pre-transmission settings.
10. Click Finish to validate the new settings.
11. Switch the printer off for 15 seconds and on again.
Now that both Windows and the printer have been configured
to use TCP/IP, the next step is to configure Windows to print
to the network printer.
NetBEUI Protocol __________________
Network Printer Settings
There are two configurable items under NetBEUI within the
printer. These can be configured using the standard set-up
utility described in “Device setup” on page 18.
Although there are some differences in configuration options
between the various Windows platforms, the procedure for
printing using NetBEUI is the same.
Please ensure the NetBEUI protocol has been installed in
Windows. This can be confirmed by checking the network
settings. If NetBEUI has not been installed please refer to the
section below.
The relevant Windows installation CD may be required and you
should follow the on-screen dialog box prompts.
Windows XP
Although you can install the NetBEUI protocol into Windows
XP, it may not be supported. You should be able to use
NetBEUI on LAN connections although you will not be able to
use this on a Remote Access Service Connections.
1. In the Start menu, select Settings then Control Panel.
Computer Name Name assigned to the printer
Workgroup
PrintServer
1
1. Although the workgroup name can be changed, it is
recommended that it remains as PrintServer.
Comment User definable description
