Olympus E-3 User Guide

60
POWER USER TIP: If you really need to cover as many lighting set
ups as possible, and there are no other E-3 camera users in the area
using remote flash operation, you can set up four different groups of
remote flash units and allocate each one of these a control channel in
the sequence 1, 2, 3 or 4. You can then set the lighting parameters for
each group on the super control panel and switch between them by
changing the command channel on the camera. You will not, however,
be able to control all four groups at once but you can switch between
the groups as needed. This will permit you, for example, to set up four
different “sets” at a music concert or on a theatrical stage and use each
group for the appropriate section of the performance without having to
run around and change setups between scenes.
BUILT-IN FLASH
The built-in flash tucked away in the top of the prism housing has
a guide number of 13 and offers the following flash modes – all

Olympus E-3 Specifications

General

Megapixel	10.1 MP
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	4/3 \
Supported aspect ratios	4:3
Maximum image resolution	3648 x 2736 pixels
Digital zoom	0 x
Optical zoom	5 x
Interface	USB
Power source	BLM-1
Video capability	No
Camera shutter speed	1/8000 - 60 s
Display diagonal	2.5 \
Magnification	1.15 x
Product color	Black
Image editing	resizing, rotating
Photo effects	black&white, Sepia
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Tungsten
Camera playback	Slide show
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Compatible memory cards	xd
Light metering	centre-weighted, spot
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE

Weight and Dimensions

Depth	74.5 mm
Width	142.5 mm
Height	116.5 mm
Weight	810 g
