ZEN V2 Units
5
Ordering Information
■ List of Models
CPU Units and Expansion I/O Units
Note: 1. Programming is not possible using only the CPU in the LED-type CPU Unit. ZEN Support Software or a Memory Cassette is required.
2. Cannot be connected to pre-V1 and V1 CPU Units.
3. The ZEN-8E1AR cannot be connected to a CPU Unit with DC power supply.
4. Product no longer available to order.
Power Supply Unit
Note: Product no longer available to order.
Refer to the ZEN-PA03024 Datasheet (Cat. No. L103) for detailed specifications.
Unit Name No. of
I/O
points
LCD
display
Power supply
voltage
Inputs Outputs Buttons,
calendar,
and clock
Analog
input
Model
CPU
Units
Standard
LCD type
10 Yes 100 to 240 VAC 6 100 to 240 VAC 4 Relays Yes No ZEN-10C1AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-10C1DR-D-V2
Transistors ZEN-10C1DT-D-V2
20 100 to 240 VAC 12 100 to 240 VAC 8 Relays No ZEN-20C1AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-20C1DR-D-V2
Transistors ZEN-20C1DT-D-V2
LED type
without
display
(See note 1.)
10 No 100 to 240 VAC 6 100 to 240 VAC 4 Relays No No ZEN-10C2AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-10C2DR-D-V2
Transistors ZEN-10C2DT-D-V2
20 100 to 240 VAC 12 100 to 240V AC 8 Relays No ZEN-20C2AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-20C2DR-D-V2
Transistors ZEN-20C2DT-D-V2
Economy
type
(Expansion
I/O Units
cannot be
connected)
10 Yes 100 to 240 VAC 6 100 to 240 VAC 4 Relays Yes No ZEN-10C3AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-10C3DR-D-V2
20 100 to 240 VAC 12 100 to 240 VAC 8 Relays No ZEN-20C3AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-20C3DR-D-V2
Communica-
tions type
9 100 to 240 VAC 6 100 to 240 VAC 3 Relays No ZEN-10C4AR-A-V2
12 to 24 VDC 12 to 24 VDC Yes ZEN-10C4DR-D-V2
ZEN Kit Set containing CPU Unit (ZEN-10C1AR-A-V2), Connecting Cable, ZEN Support Software, and manual. ZEN-KIT01-EV4
(See note 4.)
Set containing CPU Unit (ZEN-10C1DR-D-V2), Connecting Cable, ZEN Support Software, and manual. ZEN-KIT02-EV4
(See note 4.)
Expansion I/O Units 8 --- 100 to 240 VAC 4 100 to 240 VAC 4 Relays --- ZEN-8E1AR
(See notes 2, 3.)
12 to 24 VDC 12 to 24 VDC ZEN-8E1DR
(See note 2.)
---
Transistors ZEN-8E1DT
(See note 2.)
Power ratings Input voltage Output voltage Output current Model
30 W 100 to 240 VAC 24 VDC 1.3 A ZEN-PA03024
