ZEN V2 Units
25
■ ZEN Support Software Functions
Note: Always use ZEN-SOFT01-V4 as the Support Software for the V2 CPU Unit.
Creating Ladder Programs
ZEN ladder programs can be created with ease.
Note: The Edit Input Dialog Box is displayed when an input bit is
inserted. Timer, counter, and other parameter settings are also
set in the Edit Input Dialog Box. They cannot be set in the Edit
Output Dialog Box.
Monitoring Ladder Programs
The operating status can be monitored from the Support Software by
connecting to the ZEN using a Connecting Cable (ZEN-CIF01).
Simulating Ladder Programs
The simulation function makes it possible to check whether correct
operation is performed without connecting to the ZEN.
Printing Ladder Programs
Ladder programs and I/O comments, as well as timer, counter and
other parameter settings can be printed.
Note: Both RS-485 communications and the ZEN monitoring function cannot be used at the same time with Communications-type CPU Units.
The Support Software can also be used
to save files and edit comments.
Refer to the ZEN Support Software Operation Manual (Cat. No. Z184-E1-03) for details.
